AutoMeter GAUGE; WTEMP; 2 1/16in.; 300deg.F; STEPPER MOTOR W/PEAK/WRN; ELITE; W/O PRO-CONT

Part # 5656-05702SKU AU5656-05702

Universal fit

Specifications
BrandAutoMeter
Part typeEngine Coolant Temperature Gauge
Adapters IncludedYes
Bezel ColorBrushed Aluminum
Bezel StyleSuper Bezel
Face ColorBlack
Font ColorWhite
Gauge Size2.0625 in.
Gauge TypeWater Temperature
Hole Size0.0625 in.
LensFlat Clear
Lighting Color23 User Selectable Colors
Lighting TypeLED
Mounting Hardware IncludedYes
Movement TypeElectric Digital Stepper Motor
Number ColorWhite
Outer Bezel Diameter2.250 in.
Pointer ColorFluorescent Red
Sending Unit IncludedYes
Sending Unit Number2252
Temperature100-300° F
Voltage12 V
UPC / GTIN00046074142192
Warranty1 Year warranty
  • 7 User Selectable Colors To Match Visual Preferences Of Driver And Visibility Conditions
  • This Variant Gauge Is NASCAR Approved
  • Eliminates The Pro-Control Output And Wiring Present On The Standard Production
  • Set Custom Alert High And Low Points and Receive Warning Notification To Highlight The Need For Driver Attention
  • Acquire Data For Later Review With One-Touch Peak Recall Functionality
  • Gauge Kit Includes 1/8 in. NPT Temperature Sender; 3/8 in. And 1/2 in. NPT Adapters
  • Includes Wiring Harness; Mounting Hardware; Instructions For Installation
  • 12 And 16 Volt Compatible; Compatible w/Nearly Every Street Car Or Race Car Electrical System
  • Digital Stepper Motor Electric Instruments Provide Unmatched Accuracy
  • The Accuracy Of Digital Stepper Motor Gauges Is Increased By Utilizing A Self Calibration Sequence During Power Up

Description

Engines don't like high water temperatures, Heat is the enemy of performance and reliability. Keep tabs on your temps with the most accurate, quickest responding water temperature gauge on the market. AutoMeter's advanced 1/8 in. NPT temperature transducer is included as well as a direct plug in wiring harness for ease of installation.
